PIE®/CICS-Availability Plus

High Performance CICS Load-Balancing Subsystem

PIE/CICS, Productivity Integrated Environment for z/OS / CICS Transaction Server is an integrated family of common and optional components. With PIE/CICS administrators can create user profiles extending the user sessions to 99 simultaneous applications running in separate sessions.

With PIE/CICS you can build secure menus that contain multiple applications and transactions without changing existing CICS applications. When used as a CICS based application, these menus greatly simplify site navigation and shorten learning curves.

Eliminate the need for the user to Sign On to each application and/or transaction. PIE/CICS seamlessly authenticates users to external security systems (RACF, CA-ACF2, CA-Top Secret) and to internal application security. PIE/CICS Single Sign On saves valuable time and reduces user frustration.

  • OVERVIEW
    OVERVIEW
    OVERVIEW
    OVERVIEW
    OVERVIEW
    OVERVIEW
  • AT-A-GLANCE
    AT-A-GLANCE
    AT-A-GLANCE
    AT-A-GLANCE
    AT-A-GLANCE
    AT-A-GLANCE
  • FEATURES
    FEATURES
    FEATURES
    FEATURES
    FEATURES
    FEATURES
  • RESOURCES
    RESOURCES
    RESOURCES
    RESOURCES
    RESOURCES
    RESOURCES
  • REQUIREMENTS
    REQUIREMENTS
    REQUIREMENTS
    REQUIREMENTS
    REQUIREMENTS
    REQUIREMENTS

OVERVIEW

PIE/CICS-Availability Plus is an optional PIE/CICS component that provides dramatic CICS transaction response time improvements. An important part of improving response time is reducing the time a task waits in a queue before being dispatched. Typically, as the load increases on a CICS system, more tasks are queued waiting for system resources. At some point, average response time becomes a function of queue length. With a light load (less than 50% CPU usage), queue wait times are usually negligible. However, as the load approaches about 50-70% of CICS capacity, queuing time begins to increase exponentially.

As you can see from the graph below, while you may be using only half or three quarters of your CICS capacity, average response times become unacceptably long before the maximum capacity is reached.

PIE-CICS AP Response Graph.pngPIE/CICS-Availability Plus solves typical load balancing problems by allowing multiple AORs to process similar transactions. This gives you more capability to distribute work evenly across your AORs. For example, when transactions must run together in the same AOR, you can route the whole group to several AORs to evenly distribute the combined load.

If a single application has an extremely heavy load, you can isolate it and duplicate the work across several AORs.

If you want, you can distribute the load evenly by sending all your transactions to two or three AORs. PIE/CICS-Availability Plus automatically routes transactions to the appropriate AOR using one of several load balancing techniques. Because you have more control over load balancing across regions, you can minimize the occurrences of an AOR reaching its limiting capacity while other regions remain relatively idle.

DECREASED PAGING

PIE/CICS-Availability Plus often reduces the required number of AORs users create for their systems. Because users under MRO alone often want to avoid the difficulty of calculating a proper load balance, they create separate AORs for every major application; however, too many AORs can increase response time because each region requires a separate MVS address space. With more memory in use, MVS must perform more paging, degrading performance.

With PIE/CICS-Availability Plus, however, you can combine transactions into a single group and create several AORs to run all of them. The net result is fewer AORs, reducing total paging in your MVS system. Once again, response time is improved.

DECREASED DOWN TIME

MRO provides a backup facility to minimize the amount of time applications are unavailable after a region failure. You can prepare a backup AOR that can process the same applications as the working AOR. If the working region fails, CICS XRF (Extended Recovery Facility) automatically routes transactions to the backup region.

XRF has a severe limitation: the backup regions are only partially initialized. It can take several minutes for a backup region to completely initialize, which is too long for critical applications.

PIE-CICS AP Response Flow 1.png

With PIE/CICS-Availability Plus, backup AORs are always completely initialized. Users can be switched to a new AOR immediately. (If the crash causes a dump, however, PIE/CICS-Availability Plus has to wait for CICS to complete the dump before it can reroute the users; usually less than two minutes.)

PIE-CICS AP Response Flow 2.png

You can alleviate this problem to some extent by using CICS Multiregion Operation (MRO). With MRO, you can create separate CICS regions to handle terminal traffic (terminal owning regions, TORs), applications (application owning regions, AORs), and data (data owning regions, DORs). Different regions run on different CPU processors. Each region becomes a separate server operating an independent task queue. Because your CPU can process multiple CICS queues simultaneously, queues and response times are shorter.

AT-A-GLANCE

  • Reduced average transaction response time.
  • Decreased application downtime when a CICS region suffers an abend.

FEATURES

  • Even workload distribution
    Distribute CICS MRO AOR workload evenly and reduce the total number of AORs
  • Application isolation
    Heavy load application isolation and spanning onto several AORs.
  • Outbound AOR assignment
    Transaction grouping and outbound AOR assignment
  • Load balancing groups
    Create and name load balancing groups
  • Always on backup AOR
    Always on proactive online backup AORs
  • Dynamic workload balancing
    Intelligent AOR workload monitor that dynamically recognizes the smallest workload and routes transaction to the AOR with the least workload.
  • PS/2 CICS support
    PS/2 Transaction routing support
  • Unattended operation
    Automatic operation
  • Network monitoring capability
    Network Monitor

RESOURCES

REQUIREMENTS

  • Product
    PIE/CICS base
  • Mainframe
    IBM z/Architecture and compatible
  • Operating System
    MVS/ESA
    OS/390 2.10 or later
    z/OS 1.8 or later
  • Host System
    CICS Transaction Server 3.2 or later
    MRO
