CARTS/DiskStacker

Solve Your Tape Storage Problems

CARTS is a suite of z/OS software solutions that are designed to meet the unique challenges of maximizing your removable storage media utilization. When you put CARTS to work in your data center, you will see real cost savings and operational benefits. Using CARTS to manage your removable media will significantly reduce your need for additional tapes, racks and tape hardware.

  • OVERVIEW
    OVERVIEW
    OVERVIEW
    OVERVIEW
    OVERVIEW
    OVERVIEW
  • AT-A-GLANCE
    AT-A-GLANCE
    AT-A-GLANCE
    AT-A-GLANCE
    AT-A-GLANCE
    AT-A-GLANCE
  • FEATURES
    FEATURES
    FEATURES
    FEATURES
    FEATURES
    FEATURES
  • RESOURCES
    RESOURCES
    RESOURCES
    RESOURCES
    RESOURCES
    RESOURCES
  • REQUIREMENTS
    REQUIREMENTS
    REQUIREMENTS
    REQUIREMENTS
    REQUIREMENTS
    REQUIREMENTS
  • SUPPORTED ROBOTICS
    SUPPORTED ROBOTICS
    SUPPORTED ROBOTICS
    SUPPORTED ROBOTICS
    SUPPORTED ROBOTICS
    SUPPORTED ROBOTICS

OVERVIEW

CARTS-DiskStacker is an optional CARTS component that off-loads sequential disk datasets and stacks them to tape. Datasets are selected as candidates for stacking by their name or residency time on disk. Datasets are written to tape using standard MVS read/write functions. The MVS catalog is updated to reflect the new location of each dataset on tape.


After they have been stacked, dataset are read or written directly from tape without requiring DiskStacker. The MVS catalog retains the volume serial number and file sequence number of the tape dataset. All future access to the dataset is directed to the stacked tape volume.

Datasets are deleted from DASD after they are stacked and recataloged to tape; freeing up disk space. Subsequent I/O requests are directed to tape because there is only one copy of the dataset. DiskStacker differs from other products that load datasets to disk each time they are read and then migrate it to a new tape, whether or not the file was modified.

You can distribute these reports to employees at your site to get their consent before you begin actually stacking their datasets to tape.

AT-A-GLANCE

  • Rapid offload of sequential disk datasets to tape.
  • Pre stack report generation.
  • Automatic TMC update.

FEATURES

  • Simulation reporting
    Create a report with CARTS-DiskStacker run simulator.

RESOURCES

REQUIREMENTS

  • Mainframe:
    IBM z/Architecture and compatible
  • Operating System:
    MVS/ESA
    OS/390 2.10 or later
    z/OS 1.8 or later
  • Tape Device and Media Support:
    CARTS supports all tape devices that can operate with Computer Associate’s CA-1/TMS tape management including:
    • 3420 reel
    • 3480 cartridge
    • 3490 cartridge
    • 3490E cartridge
    • 3590 cartridge
    • Redwood SD-3 cartridge including all STK compatible media
  • Tape Management System and Subsystem Software:
    The following software must be fully operational on the systems that will run CARTS-TapeStacker for:
    • IBM DFSMSrmm
    • CA-Dynam/TLMS
    • CA-1/TMS
    • JES2 | All CARTS components support JES2. CARTS-MountEliminator requires Version 4.3 or higher.
    • JES3 | All CARTS components support JES3 except CARTS-MountEliminator.
    • TSO | CARTS requires Version 2 and above.
    • ISPF | CARTS requires Version 3 and above.
    • Vendor Tape Robot Software

SUPPORTED ROBOTICS

Tape Robotics

CARTS supports tape robots and their accompanying software from the following vendors:

  • StorageTek HSC
  • Memorex (SUTMYN) LMS
  • GRAU Bosch ATL
